Vivid TP
Multi Skinned GRP Skylight
Domer Vivid Thermal Panel
is a factory-assembled insulated skylight made of glass-reinforced plastic, providing high levels of natural light transmission and excellent thermal insulation, designed to match any composite roofing panel. In addition, the internal reinforcement and our engineered fiber alignment grant the possibility to use the panel in a long span due to its outstanding mechanical properties.
Domer Vivid TP is available in different fire retardant classifications conforming with the American Standard ASTM E84 and British standard BS476-7 achieving the highest classifications of GRP.
Applications:
- Rooflights
- Wall lights
- Sports centers
- Warehouses
- Green buildings
- Manufacturing Sheds
Strength and Durability
Domer offers double or triple skin GRP skylights co-extruded with the โUV Premium shieldโ to protect the panel against discoloration and yellowness. For longer protection, the GRP panel can be manufactured with โUV Platinum Shieldโ enhancing the weather-resistant with up to 30 years performance warranty.
Domer’s double or triple skinned GRP panels render diffused natural daylight into the building, ensuring the light distribution in the space without shadows or hotspots. Besides, Domer Vivid TP has an optimal thermal insulation performance and can withstand high temperatures.
Product Benefits:
- High light transmission
- High impact resistant
- Lightweight and easy to install
- “UV Premium” or “UV Platinum” shield
- Thermal Insulation
- Excellent fire performance
| Product Name | Description |
|---|---|
| Domer Vivid DS | Double skinned GRP translucent thermal panel |
| Domer Vivid DS A | Fire retardant translucent double skinned GRP conforming to American Standard ASTM E84 Class A |
| Domer Vivid DS BS | Fire retardant translucent double skinned GRP conforming to British Standard BS476-7 Class 1 |
| Domer Vivid DS Platinum | Double skinned GRP translucent thermal panel with Platinum Shield UV resistant Layer |
| Domer Vivid TS | Triple skinned GRP translucent thermal panel |
| Domer Vivid TS A | Fire retardant translucent triple skinned GRP conforming to American Standard ASTM E84 Class A |
| Domer Vivid TS BS | Fire retardant translucent triple skinned GRP conforming to British Standard BS476-7 Class 1 |
| Domer Vivid TS Platinum | Triple skinned GRP translucent thermal panel with Platinum Shield UV resistant Layer |
| Thickness | Length | Width |
|---|---|---|
| 25 - 200mm | No Limit | โค1500mm |
*customized sizes are available subject to minimum order quantity
| Type | Color |
|---|---|
| Translucent | transparent clear, opal, bluewish, greenish, yellowish, greyish, reddish, orange |
| Finishing | |
|---|---|
| Smooth | Smooth surface |
| Embossed | Embossed surface |
*Colors and Finishes can be customized subject to minimum order quantity
| Properties | Domer Vivid PS |
|---|---|
| Operating Tempreture | -20C to 80C |
| Flexural Modulus | 7700 Mpa |
| Flexural Strength | 276 Mpa |
| Tensile Modulus | 9190 Mpa |
| Tensile Strength | 137 Mpa |
| Density | 1475 kg/m3 |
| Profile | Profiles can be custom made upon request |
| Light Transmission | 72% for Clear DS | 62% for clear TS |
browse what can be done using our products
Our diverse portfolio represents decades of experience backed by a passion for quality, outstanding client service, and the latest industry technologies.
Roof Skylight
Area
Roofing
Suggested Product
Vivid, ContiRoof, ContiVault, SkyDome
Material
Polycarbonate, GRP, Hybrid
Type
Corrugated, Structured MultiWall, Vaulted
Glazed Wall
AREA
Wall
SUGGESTED PRODUCTS
ContiWall, ContiRoof, Durapoll PS, Multipoll, Vivid PS,
MATERIAL
Polycarbonate, GRP
TYPE
Multiwall, Solid, Corrugated
Roofing
AREA
Roof
SUGGESTED PRODUCTS
ContiRoof, Multipoll, Durapoll (PS), Vivid PS
MATERIAL
Polycarbonate, GRP, Hybrid
TYPE
Corrugated, MultiSkinned Structures, Standing Seam
quality products. inspired design.
unparalleled experience. exemplary service.
Common Questions & Answers
What is GRP?
GRP stands for Glass Reinforced Plastic, which is polymer resin reinforced with fiber made of glass.
GRP sheets are strong, very light in weight, and highly versatile.
Does Domer Vivid TP come with UV protection?
Domer Vivid panels are co-extruded with UV protection layer which eliminates the harmful sun rays, allowing only the healthy light rays to penetrate the building.
Domer Vivid Platinum has a very long life expectancy due to its high-end UV platinum shield layer and UV modified resin, providing a high and consistent light transmission.
Light Transmission reduction of below 12% is expected by 30 years of weathering and exposure to sunlight.
Why is important to have skylights in a building?
Daylight is always associated with improved mood, enhanced morale, and less fatigue. Studies suggest that environments with natural light have a direct impact on increasing the productivity and satisfaction of students and employees. Moreover, introducing daylight into your building will reduce the amount of artificial light decreasing your electricity cost and carbon footprint from 15 to 40 percent.
What makes Domer Vivid GRP different than conventional market GRP?
In short,
- Domer vivid panels long life expectancy due to the advanced UV resistance technology,
- Vivid panels are tough having high tensile strength,
- Excellent light transmission,
- Accuracy and consistency of the corrugation as a result of our experienced team and state of the art machinery
- Tremendous thermal insulation
- Rigid stiffener and panel, allowing crown fastener fixing for low slope roofs
