ContiWall CL40
Polycarbonate Cladding & Facade
ContiWall CL40
is a polycarbonate glazing solution compound of co-extruded polycarbonate modular panels in 40 mm thickness, thermal broken aluminum profile, and accessories designed for a translucent facade, cladding, and roofing applications.
The polycarbonate multi-diamond structure provides extraordinary stability, high impact resistance, extreme thermal insulation, and excellent light transmission. In addition, its lightweight and the seamless plug-in system ensures effortless and quick installation without the need for visible fixing, making it the ideal option for a wide range of applications.
Applications:
- Cladding
- Architectural lighting
- Internal partitions
- Rooflights
- Translucent Facades
- Rainscreen
Protection and Insulation
Domer ContiWall CL40 polycarbonate panels offer excellent protection against vandalism or accidental damages having 200 times more impact resistance than glass. ContiWall CL40 is co-extruded with a UV resistant layer blocking the harmful UV rays and providing an excellent weathering performance.
Domer ContiWall CL40 is available in different tints and transparencies to match any project requirements. Domer Solar control technology can be applied in the polycarbonate sheet allowing more natural light into the interior while reflecting the solar infrared, which creates heat. These translucent polycarbonate panels provide energy savings to the buildings while promoting daylight for a comfortable environment.
Product Benefits:
- High light transmission
- High impact resistant
- Lightweight and easy to install
- Excellent weather and UV resistant
- Outstanding Thermal Insulation
- Excellent Air-Water tightness
- Fire Retardant
| Product Name | Description |
|---|---|
| Domer ContiWall CL40 | ContiWall Polycarbonate Seamless Facade & Cladding System |
| Domer ContiWall CL40 FR | ContiWall Polycarbonate Seamless Fire Retardant conforming to European Standard EN13501-1 Class B s1 d0 |
| Thickness | Length | Width |
|---|---|---|
| 40mm | โค12m* | 500mm |
*customized sizes & colors are available subject to minimum order quantity
| Type | Color |
|---|---|
| Opaque | white, navy blue, sky blue, dark green, mint green, yellow, light grey, dark grey, red, brick red, orange |
| Translucent | transparent clear, opal, bluewish, greenish, yellowish, greyish, reddish, orange |
| Property | Test Method | Conditions | Units | Value |
|---|---|---|---|---|
| Physical | ||||
| Densitiy | D-792 | g/cm3 | 1.2 | |
| Water Absorption | D-570 | 24 hr. @ 23ยฐC | % | 0.15 |
| Mechanical | ||||
| Tensile Strength at break | D-638 | 10 mm/min | Mpa | 65 |
| Elongation at break | D-638 | 10 mm/min | % | >80 |
| Tensile Modulus of Elasticity | D-638 | 1 mm/min | Mpa | 2300 |
| Flexural Modulus | D-790 | 1.3 mm/min | Mpa | 2350 |
| Rockwell Hardness | D-785 | R scale | 125 |
| Property | Test Method | Conditions | Units | Value |
|---|---|---|---|---|
| Thermal | ||||
| Long Term Service Temperature | ยฐC | |||
| Short Term Service Temperature | ยฐC | |||
| Coefficient of Linear Expansion | D-696 | mm/mยฐC | 0.065 | |
| Thermal Conductivity | C-177 | W/mK | 0.21 | |
| System Thermal Insulation | W/m2K | 1.0 |
| Property | Test Method | Conditions | Units | Value |
|---|---|---|---|---|
| Optical | ||||
| Light Transmission | D-1003 | Clear Sheet | % | 57 |
browse what can be done using our products
Our diverse portfolio represents decades of experience backed by a passion for quality, outstanding client service, and the latest industry technologies.
Facade
AREA
Wall
SUGGESTED PRODUCTS
Contiwall, Contiroof, Multipoll, Vivaq, Vivid
MATERIAL
Polycarbonate, GRP
TYPE
Multiwall, Corrugated
Wall Cladding
AREA
Wall
SUGGESTED PRODUCT
Contiwall, Contiroof, Multipoll, Vivid
MATERIAL
Polycarbonate, GRP
TYPE
MultiWall, Solid, Corrugated
Glazed Wall
AREA
Wall
SUGGESTED PRODUCTS
ContiWall, ContiRoof, Durapoll PS, Multipoll, Vivid PS,
MATERIAL
Polycarbonate, GRP
TYPE
Multiwall, Solid, Corrugated
quality products. inspired design.
unparalleled experience. exemplary service.
Common Questions & Answers
Is ContiWall CL40 suitable to be cladded on existing building?
ContiWall polycarbonate system is an excellent solution to convert the look of your building into a modern one, Domer ContiWall is very easy to install, lightweight, insulates heat, fire retardant, and very long life expectancy of up to 25 years.
What is the heat insulation value and light transmission of ContiWall CL40??
Domer ContiWall CL40 has a light transmission up to 57% in clear color, and heat insulation U-Value of 1 w/m2K
What daylight system is suitable for flat walls?
Domer ContiWall CL40 is an excellent translucent system for flat or trapezoidal wall panels of any type, either made of conventional blocks, precast, sandwich panels, or more. ContiWall is your choice.
Does ContiWall system allow thermal expansion movement?
ContiWall plug-in system and special aluminum profiles allow thermal expansion movement for a very wide range of temperature changes.
Domer ContiWall CL40 system is proven to perform perfectly in the hottest summers and coldest winters.
